Description
Dimensions
A-Length To Fork Face
13.13ft in
B-Width Over Tires
5.91ft in
C-Overall Height
6.5ft in
D-Wheelbase
7.52ft in
E-Ground Clearance
1.19ft in
-Turning Radius Outside Tires
11ft in
-Weight
10361.73lb
Lift
F-Max Lift Height
18.84ft in
G-Max Forward Reach
11.26ft in
-Lift Capacity At Max – Height
4400.43lb
-Max Lift Capacity
5500.54lb
-Max Load At Max Height
4400.43lb
-Max Load At Max Reach
1699.77lb
-Reach At Maximum Height
22.05in
-Lift Capacity At Max – Reach
1900.39lb
-Specifications
Engine
Power
Deutz TD 2.9 L04 Tier 4f diesel 74 hp (55.4 kW)
Battery
720 CCA at 0°F (-18°C)
-Number Of Cylinders
4
-Engine Make
2349
-Engine Model
F4M2011
-Gross Power
63hp
-System Voltage
12V
-Alternator
95amps
Operational
-Turning Radius – Axle Outside
11ft in
-Operating Weight
10000.2lb
-Fuel Capacity
15.8gal
-Hydraulic System Fluid Capacity
31.8gal
-Drawbar Pull
10250lb
-Tire Size
12 x 16.5 in, 10 ply
-Transmission Type
Hydrostatic
-Max Speed – Forward
15mph
-Auxiliary Hydraulic Flow
17gal/min
-Auxiliary Hydraulic Pressure
3918psi
-Pump Flow Capacity
17gal/min
-Relief Valve Pressure
3918psi
