Description
ENGINE-
Displacement 203 in³
Net Power 73.2 HP
Engine Model Cat C3.3B DIT (turbo)
Peak Torque – 1,500 rpm – SAE J1995 195 ft·lbf
OPERATING SPECS-
Rated Operating Capacities – 35% Tipping Load 2010 lb
Tipping Load 5745 lb
Breakout Force – Tilt Cylinder 4965 lb
Ground Contact Area – With 320 mm/12.6 in Track 1483 in²
Ground Pressure – With 320 mm/12.6 in Track 6.1 psi
Rated Operating Capacities – 50% Tipping Load 2870 lb
Ground Contact Area – With 400 mm/15.7 in Track 1848 in²
Rated Operating Capacity with Optional Counterweight 3060 lb
Ground Pressure – With 400 mm/15.7 in Track 4.9 psi
Operating Weight 8987 lb
Length – Track on Ground 59 in
Overall Length – Track 78.7 in
Height – Top of Cab 83.1 in
Ground Clearance 8.9 in
Departure Angle 35°
Maximum Dump Angle 52°
Bucket Pin Height – Carry Position 7.8 in
Vehicle Width (400 mm/15.7 in tracks) 69 in
Turning Radius from Center – Coupler 54.8 in
Bucket Pin Reach – Maximum Lift 9.4 in
Vehicle Width (320 mm/12.6 in tracks) 66 in
Maximum Reach – With Arms Parallel to Ground 51.4 in
Maximum Overall Height 154.1 in
Turning Radius from Center – Bucket 86 in
Bucket Pin Height – Maximum Lift 121 in
Length – Without Bucket 108.9 in
Rack Back Angle – Maximum Height 87°
Turning Radius from Center – Machine Rear 61.5 in
Length – With Bucket on Ground 137.3 in
Clearance at Maximum Lift and Dump 89.9 in
Reach – Maximum Lift/Dump 23.9 in
